Cable Talk

PS/2 Cords

The PS/2 cords are simple, 6-pin, low-speed serial connections
commonly dedicated to a keyboard and mouse. Although these
ports on a computer may look identical at first glance, they are
not interchangeable, so you'll need to be careful to attach the
keyboard and mouse to their respective PS/2 port.  You can
add a USB adapter to the PS/2 connector to plug directly
into the USB port.

USB Cables

Used to connect all of your USB devices, A/B cables are designed to
connect from the USB port on a hub, PC or Mac to your USB device.
These fully-rated universal serial bus cables are backward compatible
with USB 1.1 and 1.0 devices and provide transfer rates up to 480
Mbps depending on USB version.  The maximum length of a
standard USB cable for USB 2.0 or earlier is 5.0 meters (16.4 ft).
The primary reason for this limit is the maximum allowed round-trip
delay of about 1,500 ns. If USB host commands are unanswered by
the USB device within the allowed time, the host considers the
command lost. When adding USB device response time, delays
from the maximum number of hubs add to the delays from
connecting cables, the maximum acceptable delay per
cable amounts to be 26 ns.

2.5mm or 3.5mm Audio Cables

Audio connectors are used to affix cables to other audio equipment,
providing electronic signal transference and grounding protection.
Connectors may be plugs, jacks, or combinations, plug type audio
 connectors are male connector includes a pin that can be
inserted into a socket. Jack  type audio connectors are female
consists of socket that are aligned to
mesh with a pin-type connector.

DVI Cables

DVI ( Digital Video Interface ) is a video cable connector designed
 at maximizing the picture quality of digital display devices such as
digital projectors and LCD screens.  DVI connectors are classified
into DVI-D ( DVI Digital ), DVI-A ( DVI Analog ), and DVI-I ( Digital
and Analog). If there is a provision for a second link, that
connector is referred to as DVI-DL (Dual Link).

HDMI Cables

HDMI ( High-Definition Multimedia Interface ) is an interface
standard used for audiovisual equipment such as high-definition
television and hone theater systems. With 19 wires wrapped
in a single cable that resembles a USB wire, HDMI is able to
carry a bandwidth of 5 Gbps ( gigabits per second ). This
is more than twice the bandwidth needed to transmit
multi-channel audio and video.  HDMI supports standard video
formats, enhanced video and high-definition. It is also backwards
compatible with DVI ( Digital Video Interface ). High-end graphics
cards featuring a DVI port can connect to a HDMI interface via
a DVI / HDMI cable. This is simply a cable with a DVI
connector on one end and a HDMI connector on the other.

Firewire IEEE 1394 Cables
